1.2 GHz Segmentable Optical node 2×2, 4 active outputs

Model: ONU1G04AP
Introduction: 1.2 GHz Segmentable Optical node 2×2, 4 active outputs
View: 47
Description


1.2 GHz technology

An extended bandwidth in downstream up to 1.2 GHz; DOCSIS 3.1 standard compliant


200 MHz technology

A possibility of extending bandwidth in upstream up to 200 MHz


GaN Technology

The Output parameters for analog and digital carriers improved for lower power consumption


Supports CWDM, DWDM

Multiwavelength technologies


The same accessories

Both equalizer and attenuator are built by fixed attenuator in order to manage accessories expediently.


RF amplifier part modular design

RF amplifier part adopts quick plug modular design, can quickly replace RF amplifier module without dismantling the RF cable connector.


RX and TX part modular design

RX and TX part adopts quick plug modular design, easy to repair replacement


NMS transponder

Reduced operating costs thanks to the remote monitoring and con guration


GREEN mode

A signicant reduction of power use thanks to optimization of its consumption


Two power supply design

Power supply Modular electronic package, enables quick maintenance
